MIL-DTL-48559B
Drawing number
4.3.2.1
Mount.
13005089
Next higher
assembly
Conformance
Requirement
None
Classification
Examination or test
criteria
paragraph
Inspection
method reference
Critical
None defined
Major
101
Presence of Plate,
100%
3.3
Visual
Identification, 13010957
102
Completeness of assembly
100%
3.3
Visual
103
Storage temperature
3 units per lot 1/
3.4.1
4.4.1
104
Operating temperature
100%
3.4.2
4.4.2
105
Shock
100%
3.4.3
4.4.3
106
Vibration "B"
100%
3.4.5
4.4.5
107
Mounting surfaces for
100%
3.5.1
4.5.1
M18A1 quadrant
108
Locating keys for M18A1
100%
3.5.2
4.5.2
quadrant
109
Mounting surfaces for
100%
3.5.3
4.5.3
gunner's quadrant
110
Cross level adjustment
100%
3.6.1
4.6.1
111
Backlash (cross level)
100%
3.6.2
4.6.2
112
Boresight elevation
100%
3.6.3
4.6.3
adjustment
113
Boresight azimuth
100%
3.6.4
4.6.4
adjustment
114
Cross level knob torque
100%
3.7
4.7
115
Boresight elevation
100%
3.8
4.8
adjustment screw torque
116
Interchangeability of
100%
3.9.1
4.9.1
mounting surface for
M18A1 quadrant
117
Interchangeability of
100%
3.9.2
4.9.2
mounting surface of
M172A1 mount
118
Interchangeability of
100%
3.9.3
4.9.3
mounting surface for
M138A1 telescope
Minor
201
Workmanship
VL-II
3.10
4.10
NOTES:
1/ Lot shall be accepted if there are 0 failures, and rejected if there are 1 or more failures.
4.3.3 Conformance inspection to be performed. The conformance inspection shall
be performed in accordance with 4.3.2.1.
