MIL-DTL-62420B(AT)
TABLE IV. Humidity profile test.
Air temperature
Relative humidity
Time (hrs)
Degrees F
Degrees C
Percent (%)
0100
100
37.8
95
0200
100
37.8
95
0300
100
37.8
95
0400
100
37.8
95
0500
100
37.8
95
0600
100
37.8
95
0700
105
40.5
81
0800
110
43.3
68
0900
120
48.9
55
1000
130
54.4
44
1100
140
60
37
1200
140
60
37
1300
150
65.6
30
1400
160
71.1
23
1500
160
71.1
23
1600
150
65.6
30
1700
150
65.6
30
1800
140
60
37
1900
130
54.4
44
2000
120
48.9
55
2100
105
40.5
81
2200
100
37.8
95
2300
100
37.8
95
2400
100
37.8
95
4.10.4 Vibration. The periscope shall be rigidly mounted to a vibration table and shall be
subjected to sinusoidal vibration along each axis in accordance with figure 2 and table V. The
sweep time shall be 15 minutes for the sweep frequency range of 5-500-5 Hz. Sweep time shall
be increased by 3 minutes if test frequencies go to 2 Hz. The frequency of applied vibration shall
be swept over the specified range in accordance with figure 3. The specified sweep time is that of
an ascending plus descending sweep and is twice the ascending time shown in figure 3 for the
specified range. The sinusoidal cycling time shall be a total of 3 hours in each of three
perpendicular axes at an ambient temperature of 140°F. At the conclusion of the test, the
periscope shall be returned to room ambient temperature (see 4.2) and pass the tests in
accordance with 4.7.1.1, 4.7.1.4, 4.7.1.5, and 4.10.6.
18
