MIL-DTL-48554B
TABLE III. Requirement/verification cross reference matrix. - Continued
Method of Verification
Class of Verification
1 - Analysis
A - First Article
2 - Demonstration
B - Conformance
3 - Examination
4 - Test
Section 3
Description
Verification
Verification
Section 4
Requirements
Method
Class
Verification
1
234
A
B
1/
3.9.1
800 mil steps (azimuth)
X
X
X
4.8.1
3.9.2
15 mil steps (azimuth)
X
X
X
4.8.2
3.9.3
Level travel (azimuth)
X
X
X
4.8.3
3.9.4
Lift (azimuth)
X
X
X
4.8.4
3.9.5
Five mil click lead (azimuth)
X
X
X
4.8.5
3.10.1
Azimuth mechanism backlash
X
X
X
4.9.1
3.10.2
Elevation mechanism backlash
X
X
X
4.9.2
3.11.1
Rapid boresight retention
X
X
X
4.10.1
3.11.2
Deflection or bearing counter
X
X
X
4.10.2
3.11.3
Correction counter excursion
X
X
X
4.10.3
3.11.4
Correction counter affect on
X
X
X
4.10.4
deflection or bearing counter
3.11.5
Correction counter setting
X
X
X
4.10.5
3.12
Open sight
X
X
X
4.11
3.13
Torque
X
X
X
4.12
3.14
Direct force, elbow assembly
X
X
X
4.13
3.15
Operability
X
X
X
4.14
3.16
Counter numerals
X
X
X
4.15
3.17.1
Reticle illumination
X
X
X
4.16
3.17.2
Counter illumination
X
X
X
4.17
3.18
Interchangeability
X
X
X
4.20
3.19
Workmanship
X
X
X
4.22
NOTES: 1/ All requirements are classified as major characteristics except 3.19 which is classified as minor.
Major and Minor characteristics are as defined in MIL-STD-1916.
